Dimension of standing
70×31×40cm
Dimension of crouching
76×31×20cm
Weight (with battery)
About 15kg
Material
Aluminium alloy + High strength engineering plastic
Voltage
28V~33.6V
Working maximum power
About 3000W
Payload
≈7kg (MAX ~ 10kg)
Speed
0 ~ 2.5m/s
Max Climb Drop Height
About 15cm
Max Climb Angle
30°
Basic Computing Power
○
Max joint Torque[1]
○
Aluminum knee joint motor
12 set
Joint set count
12 set
Body range of motion
body: -48~48º
Thigh range of motion
thigh: -200º~90º
Shank range of motion
shank: -156º~-48º
Intra-joint circuit
●
Joint Heat Pipe Cooler
●
Dimension of standing
70×31×40cm
Dimension of crouching
76×31×20cm
Weight (with battery)
About 15kg
Material
Aluminium alloy + High strength engineering plastic
Voltage
28V~33.6V
Working maximum power
About 3000W
Payload
≈8kg (MAX ~ 10kg)
Speed
0 ~ 3.5m/s
Max Climb Drop Height
About 16cm
Max Climb Angle
40°
Basic Computing Power
8-core High-performance CPU[4]
Max joint Torque[1]
About 45N.m
Aluminum knee joint motor
12 set
Joint set count
12 set
Body range of motion
body: -48~48º
Thigh range of motion
thigh: -200º~90º
Shank range of motion
shank: -156º~-48º
Intra-joint circuit
●
Joint Heat Pipe Cooler
●
Dimension of standing
70×31×40cm
Dimension of crouching
76×31×20cm
Weight (with battery)
About 15kg
Material
Aluminium alloy + High strength engineering plastic
Voltage
28V~33.6V
Working maximum power
About 3000W
Payload
≈8kg (MAX ~ 12kg)
Speed
0 ~ 3.7m/s (MAX ~ 5m/s)
Max Climb Drop Height
About 16cm
Max Climb Angle
40°
Basic Computing Power
8-core High-performance CPU
Max joint Torque[1]
About 45N.m
Aluminum knee joint motor
12 set
Joint set count
12 set
Body range of motion
body: -48~48º
Thigh range of motion
thigh: -200º~90º
Shank range of motion
shank: -156º~-48º
Intra-joint circuit
●
Joint Heat Pipe Cooler
●
